Olympus OmniScan X3 64-Channel Flaw Detector

Olympus OmniScan X3 64-Channel Flaw Detector

Olympus OmniScan X3 64-Channel Flaw Detector – Housed in the field-proven rugged and portable OmniScan X3 enclosure, the OmniScan X3 64 flaw detector’s powerful focusing capabilities supported by its larger element-aperture capacity enable you to fully exploit 64-element phased array probes and 128-element aperture TFM. Utilize its enhanced performance to meet the inspection challenges of thick and attenuative materials and expand your potential to develop new procedures for a wider range of applications.

Package includes:

– OmniScan X3 64 flaw detector 64:128PR
– OmniScan MXU software
– 10L16-9.6X10-A10-P-2.5-OM: Standard Phased Array Probe, 10 MHz Linear Array, 16 Elements
– SA10-IHC: Standard removable IHC option for SA10 wedges
– SA10-N55S: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD3.5: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD4.5: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD6.625: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD8.625: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD10.750: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD12.750: Standard wedge for angle beam phased-array probe A10
– SA10-N55S-AOD24: Custom Wedge for Angle Beam Phased-Array Probe A10
– 5L32-32X10-A32-P-5-OM: Standard Phased Array Probe, 5.0 MHz Linear Array, 32 Elements
– SA32-N55S-IHC: Standard Wedge for Angle Beam Phased-Array Probe Type A31
– ENC1-5-LM: Mini encoder, 5 m cable, waterproof with Lemo connector
– WTR-SPRAYER-8L: Portable manual couplant feed unit
– TB7567-1: NAVSHIPS Block. 1018 Steel
– 93 Wh lithium-ion battery
– Spare screen protector
– DC charger with power cord
– USB key with MXU Software and User’s Manuals
– Empty USB key for file transfer purposes
– Complimentary OmniPC analysis software
– Calibration certificate
– Transport case

Specifications:

Models : OmniScan X3 64
Configuration : 64:128PR
Applications : Multi-group high-productivity very thick weld PA & TOFD, Austenitic/CRA/Disimilar metal weld, High-productivity TFM, High Temperature hydrogen attack (HTHA), Advanced application development
Pulsers (PA) : 64
Receivers : 128
TFM Elements : 128
UT Channels (P/R) : 2
Groups : Up to 8 total
TFM: up to 4
Bandwidth Frequency : 0.2 MHz to 26.5 MHz
Maximum Pulse Width (PA) : 1000 ns
Voltage PA : 10 Vpp, 20 Vpp, 40 Vpp, 80 Vpp, 120 Vpp, and 160 Vpp / Bipolar Square Pulse
Internal SSD Storage Capacity : 1 TB
