Description

CUTERA EXCEL V+

The Excel V+ is FDA-cleared and intended for treatment of a wide array of benign conditions using both wavelengths:

• Vascular lesions: telangiectasia, facial/leg veins, angiomas, port-wine stains, venous lakes, rosacea, diffuse redness, poikiloderma, hemangiomas
• Pigmented lesions: lentigines, nevi, ephelides, dyschromia, seborrheic keratoses
• Cutaneous lesions: warts, skin tags, bruising, acne scars, wrinkles, striae, pseudofolliculitis barbae, mild-to-moderate acne
• Hair removal: small-area hair reduction

excel V+ in action

Two clinically proven wavelengths treat large spot sizes up to 16 mm. Applications include rosacea, diffuse redness, facial veins, leg veins, periorbital veins, angiomas, port wine stains, poikiloderma, wrinkles, venous malformations, bruising, inflammatory acne, benign pigmented lesions, age spots, small-area hair removal, scars, and acne scars.

excel V+ technology

Four compatible handpieces give you even more versatility with excel V+. Deliver the micro-pulsed 532 nm wavelength with our Genesis V™ handpiece, customize spot size and wavelength using the fully-integrated CoolView™, or use the pencil-like Dermastat handpieces to precisely treat small vascular and pigmented lesions.

CoolView™ Handpiece

Wavelengths: 532 nm & 1064 nm (switchable)

Spot Sizes: 2–16 mm (adjustable in small increments)

Cooling: Contact cooling with sapphire window (5–20 °C)

Primary Functions:

• Treats both superficial (532 nm) and deeper vascular lesions (1064 nm)
• Ideal for telangiectasias, rosacea, angiomas, leg veins, and venous lakes
• Also used for pigmented lesions (lentigines, sunspots) and small-area hair removal
• Large spot sizes allow fast treatment of extensive areas

Best For:

• Redness/diffuse rosacea
• Large vessels (legs, face)
• Pigment removal
• Bruising (post-injectable)



PRODUCT SPECIFICATIONS

Dimensions: ~40 cm W × 97 cm H × 79 cm D (about 16″ × 35″ × 24″)

Weight: ~86 kg (185 lb)

Power requirements: 110–120 VAC, 20 A

Dual-wavelength system:

• 532 nm KTP (LBO‑enhanced solid-state) – ~50% more powerful than Excel V 

• 1064 nm Nd:YAG for deeper targets

Spot size flexibility:

• Adjustable from 2 mm up to 16 mm (in some sources 14 mm) in 0.5–1 mm increments

Pulse duration range:

• 0.3 ms – 300 ms total system; CoolView (KTP) 1.5–40 ms; YAG 5–300 ms

Fluence (energy density):

• KTP: roughly 1.8–42 J/cm²
• Nd:YAG: up to 300 J/cm²

Repetition rate:

• KTP: 2–12 Hz
• Nd:YAG: up to 10 Hz (CoolView) or 0–2 Hz in some configs *
